AS 2129:2000 TABLE D
TAB D
LENGTH THROUGH HUB
DRILLING DATA
TAB D
NOMINAL PIPE SIZE
FLANGE OUTSIDE DIAMETER
THICKNESS OF FLANGE (Refer Note.1)
BOSSED SOW
WELD NECK
PITCH CIRCLE DIAMETER
BOLT HOLE DIAMETER
NUMBER OF BOLT HOLES
NOMINAL PIPE SIZE
MM
INCH
OD
T
L
L1
PCD
H
﹟
MM
INCH
15
1/2
95
5
15
27
67
14
4
15
1/2
20
3/4
100
5
16
27
73
14
4
20
3/4
25
1
115
5
16
27
83
14
4
25
1
32
1 1/4
120
6
17
31
87
14
4
32
1 1/4
40
1 1/2
135
6
19
35
98
14
4
40
1 1/2
50
2
150
8
21
37
114
18
4
50
2
65
2 1/2
165
8
24
40
127
18
4
65
2 1/2
80
3
185
10
26
45
146
18
4
80
3
90
3 1/2
205
10
27
45
165
18
4
90
3 1/2
100
4
215
10
29
51
178
18
4
100
4
125
5
255
13
32
57
210
18
8
125
5
150
6
280
13
32
61
235
18
8
150
6
200
8
335
13
35
64
292
18
8
200
8
225
9
370
16
41
73
324
18
8
225
9
250
10
405
16
43
80
356
22
8
250
10
300
12
455
19
48
89
406
22
12
300
12
350
14
525
22
95
470
26
12
350
14
375
15
550
22
495
26
12
375
15
400
16
580
22
521
26
12
400
16
450
18
640
25
584
26
12
450
18
500
20
705
29
641
26
16
500
20
525
21
735
29
673
26
16
525
21
550
22
760
29
699
30
16
550
22
600
24
825
32
756
30
16
600
24
700
28
910
35
845
30
20
700
28
750
30
995
41
927
33
20
750
30
800
32
1060
41
984
36
20
800
32
850
34
1090
44
1016
36
20
850
34
900
36
1175
48
1092
36
24
900
36
1000
40
1255
51
1175
36
24
1000
40
1050
42
1335
54
1251
36
28
1050
42
1200
48
1490
60
1410
36
32
1200
48
NOTES:
(1) The minimum flange thickness in carbon steel flanges will be 12mm. (2) Bore sizes to suit ASME B 36.10B36.19 pipe unless otherwise specified. (3) Flanges are generally supplied flat faced.
